Design Features

The system features a reinforced galvanized steel frame lined with phenolic resin-coated plywood (15 mm / 9/16") that produces a smooth, fair-faced concrete finish. Panels are modular, providing flexibility in wall heights and widths, and they can be quickly aligned or joined using manual or adjustable clamps. Larger panel configurations are designed for crane handling, while lightweight variants like Alisply-M Walls can be hand-set for projects not requiring heavy lifting. Accessories such as chamfer strips, channels, and bulkheads can be attached to create customized textures and architectural details in the concrete.

Applications

Alisply wall forms are used in a wide range of construction projects, including:

• Vertical concrete walls for residential, commercial, and industrial buildings.

• Circular or curved walls with on-site adjustable radii for custom curves.

• One-sided walls or bulkheads where only one face requires support.

• Complex architectural shapes and irregular geometries thanks to modular sizing and compatibility with other Alsina formwork systems.

• Infrastructure and civil engineering projects, such as retaining walls, water treatment plants, reservoirs, and tunnels, where precise and reusable formwork improves efficiency.

Advantages

• Efficiency: Fast assembly and alignment reduce material handling time.

• Reusability: Durable steel and phenolic plywood support multiple uses.

• Safety: Compatible with crane handling, walkways, and safety platforms to protect workers.

• Flexibility: Supports various wall heights (up to 30 feet / 9 m) and thicknesses and integrates with other Alsina systems like climbing platforms and multipurpose panels.

• Quality Finish: Phenolic plywood surface ensures high-quality concrete surfaces with minimal finishing work.

Alisply Alsina wall forms are widely used in modern concrete construction for building high-quality walls efficiently and safely, adapting to straight, curved, and complex designs, and suitable for both small-scale construction and large civil engineering projects.
